MAIN FEATURES

Computer CNC system, control by touch control and operation more easy andquickly, high degree of automation.

Roller type feeding mechanism, touch control digital input on the screen, thecutting material inlet from one end of machine, outlet from another end ofmachine after cutting and indentation, configuration multl-windingdischargerack, multi-layer punching. Number of punching reach up to 20-30 times/min,highefficient of productivity.

The servo motor feeding, high accuracy of feeding, with corrective device,reduce the leftover material breakage and save raw materials.

Dynamic punching repeat precision within overall punching area: + 0.1mm,
operation noise of equipment: + 60 db.

Automation of feeding and discharging, greatly reduce the manpower resource.

The upper working table equipped with adjustable cutting mould clamping
device, change the cutter convenient quickly.

The front and back of working table equipped with safety grating protection
device, CE safety standards, and most safety.

Can manual pick up the products, can also machinery pick up the products,can be installation recovery device for side material.

With water cooler, dissipate heat more sufficiently, effectively keeppunching force and make the machine more durable in use.
